CADE Reef Frag S3/F 1200

Beskrivning

The CADE Reef S3/F is our premium range of customisable, sump filtered saltwater Aquariums designed specifically for the advanced reef aquarist. The all-new Reef S3/F aims to redefine shallow Reef Aquaria combining advanced features, cutting edge functionality and premium construction materials to create a system that assembles with effortless simplicity.

The Reef S3/F series has been expertly crafted to enable the Reef Aquarist to build a truly personalised Reef Aquarium system incorporating industry leading filtration design for unparalleled life support versatility. In its entirety the S3 range combines functional design and unique sophistication that both compliments contemporary home decor whilst fulfilling all of your Reef keeping requirements.

Key Features

Tank

Tank dimensions: 1200x700x350mm

Internal dimensions (LxWxH): 1200x610x350mm

Total volume: 332L / 88gal

Display volume: 252L / 66.5gal

Glass type: Opti-Clear low Iron.

Glass thickness: 12mm

Rimless

Polycarbonate Jump Guard covering the tank, weir & ATO

Light mount provision locations: Rear & Side Mount

Jet black rear glass panel (single sheet)

White film applied underneath the tank (bare bottom ready)

Concealed slimline Weir with 2 inlet vents (surface & low) for optimal intake flow and blockage redundancy

Tank return flow x2 c/w adjustable outlets.

Gravity-fed ATO, 27L / 7 gal

Pre-installed tank plumbing out of the box.

Cabinet

Dimensions: 1200×700×900mm

Aluminium frame and doors

100% waterproof and corrosion-proof

Cabinet pre-assembled with sump installed

Device display panel (door) behind the cabinets front door c/w integrated cable / power pack management boxes.

Device display and power management behind Right-side door c/w power switches and cable / power pack management boxes.

Dry space dimensions (LxWxH): 321x610x580mm

Power board c/w switches (16 sockets)

Left-side sump access for easy maintenance

Pre installed foam tank mat

Adjustable levelling feet

Accessories shelf

Sump & Filtration

Tinted glass sump

Roller mat ready (no filter socks)

Triton ready ’Triton Tray’. Can also be used as a Frag Rack

Protein skimmer / reactor chamber

Bio/chemical media chamber with removable media baskets

Return pump chamber with ATO float valve

Reactor/chiller feed outlets: x3

Plumbing

Newly designed pre-fabricated quick-fit plumbing system with all tank-side plumbing pre-installed

Simply screw fit the cabinet connections to the tank and connect the joiners to complete installation. The quickest Aquarium plumbing installation on the market.

Full Flowcolour plumbing system including pipes, taps, and connections, finished in blue & grey.

Dual down-flow pipes (main + emergency) with fine-tune gate valve

Concealed return plumbing with non return valve and directional outlet nozzle in the tank.

Tank outlets: x2

Silent Operation.

Why Choose the CADE Reef S3?

The S3/F Series is ’Inspired by Aquarists and Crafted for Corals’, combining advanced functionality with premium build quality to deliver a Reef system with unparalleled versatility and functionality.

The S3/F Series sets a new standard in professional shallow Reef Aquariums, featuring advanced device and cable management, a triple-intake weir, roller-mat ready sump, quick-fit plumbing, and a 100% waterproof all-aluminium cabinet for unmatched durability.

Warranty

CADE products are covered by a 2 year limited warranty from the date of purchase covering manufacturers defects. Warranty does not cover damage caused by usage such as scratches and chips to glass consequent to normal wear and tear.
